We persistently pursue better quality, and use our unremitting efforts to become a reliable Hand Start Portable Generator, High Performance Petrol Engine, Gasoline High Lift Pump partner for customers! All of our functional departments, teams and employees are directed towards the development of the company, setting decomposition goals and completing them. We uphold the enterprise spirit of "integrity, honesty, unity and hard work" and the enterprise tenet of "self-improvement, pioneering, honest management and striving for the top", and are committed to creating and realizing a dynamic enterprise management mode with high enthusiasm. In the increasingly competitive market, we are willing to build a bridge of friendship and create a good trade atmosphere together. We are equipped with professional technical service personnel to provide customers with quality products and a full range of attentive services.
SPECIFICATIONS | R80 | R100 | R210 |
Engine type | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) |
Bore×Stroke | 52×37mm | 56×40mm | 70×55mm |
Displacement | 78.5ml | 98ml | 212ml |
Compression ratio | 9.0 : 1 | 8.5 : 1 | 9.0 : 1 |
Net power | 1.4kw / 3600rpm | 1.8kw / 3600rpm | 4.4kw / 3600rpm |
Net torque | 3.6N.m / 2500rpm | 5N.m / 2500rpm | 12N.m / 2500rpm |
PTO shaft rotation | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) |
Ignition system | Transistorized magneto ignition | Transistorized magneto ignition | Transistorized magneto ignition |
Starting system | Recoil / Electric starter | Recoil / Electric starter | Recoil / Electric starter |
lubrication system | Forced splash | Forced splash | Forced splash |
Carburetor | Flat suction valve carburetor | Flat suction valve carburetor | Flat suction valve carburetor |
Governor system | Centrifugal mechanical | Centrifugal mechanical | Centrifugal mechanical |
Air cleaner | Foam | Foam | Dual elements(paper or foam) |
Oil capacity | 0.35L | 0.35L | 0.55L |
Fuel tank capacity | 1.8L | 1.8L | 3.6L |
Dimensions(L x W x H) | 310×290×310mm | 310×290×310mm | 390×320×345mm |
Net weight | 10kg | 10kg | 16kg |
Fuel consumption | ≤450g/kw·h | ≤450g/kw·h | ≤395g/kw·h |
SPECIFICATIONS | R225 | R300 | R390 |
Engine type | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) |
Bore×Stroke | 70×58mm | 80×60mm | 88×64mm |
Displacement | 223m | 301ml | 389ml |
Compression ratio | 9.0 : 1 | 8.5 : 1 | 8.5 : 1 |
Net power | 4.5kw / 3600rpm | 6.0kw / 3600rpm | 7.8kw / 3600rpm |
Net torque | 13N.m / 2500rpm | 18N.m / 2500rpm | 25N.m / 2500rpm |
PTO shaft rotation | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) |
Ignition system | Transistorized magneto ignition | Transistorized magneto ignition | Transistorized magneto ignition |
Starting system | Recoil / Electric starter | Recoil / Electric starter | Recoil / Electric starter |
lubrication system | Forced splash | Forced splash | Forced splash |
Carburetor | Flat suction valve carburetor | Flat suction valve carburetor | Flat suction valve carburetor |
Governor system | Centrifugal mechanical | Centrifugal mechanical | Centrifugal mechanical |
Air cleaner | Dual elements(paper or foam) | Dual elements(paper or foam) | Dual elements(paper or foam) |
Oil capacity | 0.55L | 1.1L | 1.1L |
Fuel tank capacity | 3.6L | 5.4L | 6.5L |
Dimensions(L x W x H) | 390×320×345mm | 465×415×440mm | 465×415×440mm |
Net weight | 16.5kg | 30.5kg | 30.5kg |
Fuel consumption | ≤395g/kw·h | ≤374g/kw·h | ≤374g/kw·h |
SPECIFICATIONS | R420 | R500-V |
Engine type | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) |
Bore×Stroke | 90×66mm | 94×72mm |
Displacement | 420ml | 500ml |
Compression ratio | 8.5 : 1 | 9.0 : 1 |
Net power | 8.8kw / 3600rpm | 12.5kw / 3600rpm |
Net torque | 26.5N.m / 2500rpm | 31N.m / 2500rpm |
PTO shaft rotation | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) |
Ignition system | Transistorized magneto ignition | Recoil starter |
Starting system | Recoil / Electric starter | Recoil / Electric starter |
lubrication system | Forced splash | Forced splash |
Carburetor | Flat suction valve carburetor | Flat suction valve carburetor |
Governor system | Centrifugal mechanical | Centrifugal mechanical |
Air cleaner | Dual elements(paper or foam) | Dual elements(paper or foam) |
Oil capacity | 1.1L | 1.2L |
Fuel tank capacity | 6.5L | 7.0L |
Dimensions(L x W x H) | 465×415×440mm | 475×425×440mm |
Net weight | 31kg | 32kg |
Fuel consumption | ≤374g/kw·h | ≤374g/kw·h |
•Experienced engineering design team for less failure and quality issues;
We are a modern enterprise with unified and standardized management mechanism and advanced production equipment. We have also established a complete quality assurance system to ensure the good reputation and the excellent quality of Single Cylinder 4-Stroke 5.5-7.0HP Gasoline Engine (LT-168F LT168F-1 LT170F). With full enthusiasm and brand-new attitude, we will create brilliance with the majority of users and friends. We strive to build an enterprise with scientific structure, excellent culture, and obvious competitiveness and influence in the industry.
