In order to serve our customers more effectively, we can also develop individual Quality Copper Wire Gasoline Generator, Single Phase Inverter Generator, Recoil Start Gas Portable Generator for our customers according to their needs. What we can do is to continuously innovate and improve our products, strictly control the quality and service links, and provide more perfect, reliable and cost-effective products, so that customers in different fields can have more choices. We carry out scientific and technological research to keep up with the times and lead the trend of the times. Holding quality first, insisting on service first--we invested in the construction of a finishing production line, and cultivated a skilled and stable production and quality management team.
SPECIFICATIONS | RV340 | RV450 |
Engine type | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) |
Bore×Stroke | 88×56mm | 92×67.6mm |
Displacement | 340.6ml | 449.4ml |
Compression ratio | 8.0 : 1 | 8.7 : 1 |
Net power | 8.15kw / 3600rpm | 11kw / 3600rpm |
Net torque | 23.5N.m / 2500rpm | 31N.m / 2500rpm |
PTO shaft rotation | Counterclockwise(vertical output) | Counterclockwise(vertical output) |
Ignition system | Transistorized magneto ignition | Transistorized magneto ignition |
Starting system | Recoil & Electric starter / Electric starter | Electric starter / Electric starter |
lubrication system | Forced splash | Forced splash |
Carburetor | Flat suction valve carburetor | ECU EFI system |
Governor system | Centrifugal mechanical | Electronic speed regulation |
Air cleaner | Foam + cylinder paper | Foam + cylinder paper |
Oil capacity | 1.1L | 1.5L |
Fuel tank capacity | 3.7L | —— |
Dimensions(L x W x H) | 421×442×316mm | 463×460×302 |
Net weight | 24.5kg | 32.5kg |
SPECIFICATIONS | R670 | R670-A | R670D |
Engine type | V-Twin cylinder,4-stroke(OHV) | Single cylinder, 4-Stroke(OHV) | Double cylinder, four stroke(OHV) |
Bore×Stroke | 78×70mm | 99×87mm | 78×70mm |
Displacement | 670ml | 670ml | 669ml |
Compression ratio | 8.1 : 1 | 8.0 : 1 | 8.5 : 1 |
Net power | 15.5kw / 3600rpm | 14.5kw / 3600rpm | 15.5kw / 3600rpm |
Net torque | 45N.m / 2500rpm | 39N.m / 2500rpm | 45N.m / 2500rpm |
PTO shaft rotation | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) |
Ignition system | Transistorized magneto ignition | Transistorized magneto ignition | Recoil starter |
Starting system | Recoil / Electric starter | Recoil / Electric starter | Electric starter |
lubrication system | Forced splash | ForcedSplash | ForcedSplash |
Carburetor | Flat suction valve carburetor | Flat suction valve carburetor | Double chamber float carburetor |
Governor system | Centrifugal mechanical | Centrifugal mechanical | Electronic & mechanical speed contro |
Air cleaner | Dual elements(paper or foam) | Dual elements(paper or foam) | Dual elements(paper or foam) |
Oil capacity | 1.5L | 1.7 | 1.6L |
Fuel tank capacity | ——— | ---- | ---- |
Dimensions(L x W x H) | 457×351×460mm | 591×389×322mm | 550×460×345mm |
Net weight | 45kg | 42kg | 45kg |
Fuel consumption | ≤374g/kw·h | ≤370g/kw·h | ≤370g/kw·h |
SPECIFICATIONS | R740D | R999D | R500-V |
Engine type | Double cylinder, four stroke(OHV) | Double cylinder, four stroke(OHV) | Single cylinder, 4-Stroke(OHV) |
Bore×Stroke | 82×70mm | 90×78.5mm | 94×72mm |
Displacement | 739.3ml | 999ml | 500ml |
Compression ratio | 8.5 : 1 | 8.7 : 1 | 9.0 : 1 |
Net power | 16.8kw / 3600rpm | 24.5kw / 3600rpm | 12.5kw / 3600rpm |
Net torque | 47N.m / 2500rpm | 68N.m / 2500rpm | 31N.m / 2500rpm |
PTO shaft rotation | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) |
Ignition system | Transistor ignition | Recoil starter | Recoil starter |
Starting system | Electric starter | Electric starter | Recoil / Electric starter |
lubrication system | ForcedSplash | ForcedSplash | Forced splash |
Carburetor | Flat suction valve carburetor | Double chamber float carburetor | Flat suction valve carburetor |
Governor system | Electronic & mechanical speed contro | Electronic & mechanical speed contro | Centrifugal mechanical |
Air cleaner | Dual elements(paper or foam) | Dual elements(paper or foam) | Dual elements(paper or foam) |
Oil capacity | 1.6L | 2.4L | 1.2L |
Fuel tank capacity | ---- | ---- | 7.0L |
Dimensions(L x W x H) | 550×460×345mm | 510×(385+96)×558mm | 475×425×440mm |
Net weight | 45kg | 50kg | 32kg |
Fuel consumption | ≤370g/kw·h | ≤370g/kw·h | ≤374g/kw·h |
We now have modern production workshops, advanced production equipment, professional production lines and complete supporting facilities, and professionally design and manufacture Powerful Reliable and Durable Gasoline/Petrol Engine 420cc suitable for different users. The reorganization of our company makes the enterprise full of vigor and vitality, and makes a qualitative leap in the company's technical strength, processing and manufacturing capacity, industrial testing means and product quality. The company adheres to open cooperation and innovation, starting from maintaining the unification of global standards, building industrial ecological alliances, embracing global open source, and promoting key technological innovations, to aggregate, co-construct, and share the elements of the entire industry to develop together with all industries.
