SPECIFICATIONS |
R1250ISP-3 |
R2000ISP-2 |
R2500iS |
|
Engine type |
Single cylinder, 4-Stroke(OHV) |
Single cylinder, 4-Stroke(OHV) |
Single cylinder, 4-Stroke(OHV) |
|
Displacement |
60ml |
79.7ml |
60 x 43mm |
|
Bore×Stroke |
45×38mm |
48.6×43mm |
122ml |
|
Compression ratio |
8.2 : 1 |
8.7 : 1 |
8.2:1 |
|
Rated frequency |
60Hz |
60Hz |
50Hz |
|
Rated voltage |
120V |
120V |
230V |
|
Rated power |
1.0kw |
1.6kw |
2.3kw |
|
Max. power |
1.1kw |
1.95kw |
22.5kw |
|
DC output |
12V /5A |
12V / 8.3A |
12V/8.3A |
|
Starting system |
Recoil starter |
Recoil starter |
Recoil |
|
Fuel tank capacity |
3L |
4.2L |
4.5L |
|
Full load continuum running time |
4h |
3.5h |
3 h |
|
1/2 load continuum running time |
6h |
6h |
5 h |
|
Noise (7m) |
63dB |
68dB |
67 dB |
|
Dimensions (L×W×H) |
460×270×390mm |
510×300×475mm |
520x320x450mm |
|
Net weight |
14kg |
24.5kg |
25kg |
|
SPECIFICATIONS |
R3000iE |
R8000iE-4 |
|
Engine type |
Single cylinder, 4-Stroke(OHV) |
Single cylinder, 4-Stroke(OHV) |
|
Displacement |
70 x55mm |
90 x66mm |
|
Bore×Stroke |
212ml |
420ml |
|
Compression ratio |
8.0 : 1 |
8.5 : 1 |
|
Rated frequency |
50Hz |
50Hz |
|
Rated voltage |
230V |
230V |
|
Rated power |
3.2kw |
6.8kw |
|
Max. power |
3.5kw |
7.5kw |
|
DC output |
12V/8.3A |
12V/8.3A |
|
Starting system |
Recoil / Electric starter |
Recoil / Electric starter |
|
Fuel tank capacity |
8.3 L |
24L |
|
Full load continuum running time |
5 h |
6 h |
|
1/2 load continuum running time |
8.5 h |
8 h |
|
Noise (7m) |
66 dB |
=76 dB(7m) |
|
Dimensions (L×W×H) |
605x432x493mm |
695x641x643mm |
|
Net weight |
44.5kg |
76kg |
|
SPECIFICATIONS |
R3500i |
R5500IiD |
R8000iD |
|
Engine type |
Single cylinder, 4-Stroke(OHV) |
Single cylinder, 4-Stroke(OHV) |
Single cylinder, 4-Stroke(OHV) |
|
Bore×Stroke |
70 x55mm |
80 x 60mm |
90 x 66mm |
|
Displacement |
212ml |
301ml |
212ml |
|
Compression ratio |
8.5 : 1 |
8.2 : 1 |
8.0 : 1 |
|
Rated frequency |
50Hz |
50Hz |
50Hz |
|
Rated voltage |
230V |
230V |
230V |
|
Rated power |
3.2kw |
5.0kw |
7.0kw |
|
Max.power |
3.5kw |
5.5kw / |
3.5kw / |
|
DC output |
12V/8.3A |
12V/8.3A |
12V/8.3A |
|
Starting system |
Recoil / Electric starter |
Recoil / Electric starter |
Recoil / Electric starter |
|
Fuel tank capacity |
7 L |
15 L |
15 L |
|
Full load continuum running time |
4.3 h |
9h |
6.5 h |
|
1/2 load continuum running time |
7 h |
12 h |
10 h |
|
Noise(7m) |
676 dB |
676 dB |
676 dB |
|
Dimensions(L x W x H) |
502x350x495mm |
605x514x537mm |
605x514x537mm |
|
Net weight |
30kg |
60kg |
65kg |
