SPECIFICATIONS | R80 | R100 | R210 |
Engine type | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) |
Bore×Stroke | 52×37mm | 56×40mm | 70×55mm |
Displacement | 78.5ml | 98ml | 212ml |
Compression ratio | 9.0 : 1 | 8.5 : 1 | 9.0 : 1 |
Net power | 1.4kw / 3600rpm | 1.8kw / 3600rpm | 4.4kw / 3600rpm |
Net torque | 3.6N.m / 2500rpm | 5N.m / 2500rpm | 12N.m / 2500rpm |
PTO shaft rotation | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) |
Ignition system | Transistorized magneto ignition | Transistorized magneto ignition | Transistorized magneto ignition |
Starting system | Recoil / Electric starter | Recoil / Electric starter | Recoil / Electric starter |
lubrication system | Forced splash | Forced splash | Forced splash |
Carburetor | Flat suction valve carburetor | Flat suction valve carburetor | Flat suction valve carburetor |
Governor system | Centrifugal mechanical | Centrifugal mechanical | Centrifugal mechanical |
Air cleaner | Foam | Foam | Dual elements(paper or foam) |
Oil capacity | 0.35L | 0.35L | 0.55L |
Fuel tank capacity | 1.8L | 1.8L | 3.6L |
Dimensions(L x W x H) | 310×290×310mm | 310×290×310mm | 390×320×345mm |
Net weight | 10kg | 10kg | 16kg |
Fuel consumption | ≤450g/kw·h | ≤450g/kw·h | ≤395g/kw·h |
SPECIFICATIONS | R225 | R300 | R390 |
Engine type | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) |
Bore×Stroke | 70×58mm | 80×60mm | 88×64mm |
Displacement | 223m | 301ml | 389ml |
Compression ratio | 9.0 : 1 | 8.5 : 1 | 8.5 : 1 |
Net power | 4.5kw / 3600rpm | 6.0kw / 3600rpm | 7.8kw / 3600rpm |
Net torque | 13N.m / 2500rpm | 18N.m / 2500rpm | 25N.m / 2500rpm |
PTO shaft rotation | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) |
Ignition system | Transistorized magneto ignition | Transistorized magneto ignition | Transistorized magneto ignition |
Starting system | Recoil / Electric starter | Recoil / Electric starter | Recoil / Electric starter |
lubrication system | Forced splash | Forced splash | Forced splash |
Carburetor | Flat suction valve carburetor | Flat suction valve carburetor | Flat suction valve carburetor |
Governor system | Centrifugal mechanical | Centrifugal mechanical | Centrifugal mechanical |
Air cleaner | Dual elements(paper or foam) | Dual elements(paper or foam) | Dual elements(paper or foam) |
Oil capacity | 0.55L | 1.1L | 1.1L |
Fuel tank capacity | 3.6L | 5.4L | 6.5L |
Dimensions(L x W x H) | 390×320×345mm | 465×415×440mm | 465×415×440mm |
Net weight | 16.5kg | 30.5kg | 30.5kg |
Fuel consumption | ≤395g/kw·h | ≤374g/kw·h | ≤374g/kw·h |
SPECIFICATIONS | R420 | R500-V |
Engine type | Single cylinder, 4-Stroke(OHV) | Single cylinder, 4-Stroke(OHV) |
Bore×Stroke | 90×66mm | 94×72mm |
Displacement | 420ml | 500ml |
Compression ratio | 8.5 : 1 | 9.0 : 1 |
Net power | 8.8kw / 3600rpm | 12.5kw / 3600rpm |
Net torque | 26.5N.m / 2500rpm | 31N.m / 2500rpm |
PTO shaft rotation | Counterclockwise(horizontal shaft output) | Counterclockwise(horizontal shaft output) |
Ignition system | Transistorized magneto ignition | Recoil starter |
Starting system | Recoil / Electric starter | Recoil / Electric starter |
lubrication system | Forced splash | Forced splash |
Carburetor | Flat suction valve carburetor | Flat suction valve carburetor |
Governor system | Centrifugal mechanical | Centrifugal mechanical |
Air cleaner | Dual elements(paper or foam) | Dual elements(paper or foam) |
Oil capacity | 1.1L | 1.2L |
Fuel tank capacity | 6.5L | 7.0L |
Dimensions(L x W x H) | 465×415×440mm | 475×425×440mm |
Net weight | 31kg | 32kg |
Fuel consumption | ≤374g/kw·h | ≤374g/kw·h |
•Experienced engineering design team for less failure and quality issues;
