PRODUCT INTRODUCTION
·Novel appearance, distinctly higher power output, smaller size, lighter weight, lower THD and stable frequency, low fuel consumption，comparing with the off shelf remarkable brand open frame generators.
·Precisely controlled ignition, engine speed intelligent control, high efficiency but saving fuel consumption.
·Smart circuit protection, reliable safety.
·Integrated humanization design, inverter control, clearly visible, accessible easy operation on the front panel.
·With parallel kit (for model R4000iP only) and the functionality of energy saving, returning and protection, faulty operation alert and dual USB device.
·Low engine oil alarm and automatic shut-down to protect engine from working at low oil level.
·Full direction wheel, easy to handle
SPECIFICATIONS | R4000i /R4000ip | R6250i /R6250ip | R8750iD/R8750iDP |
Certification | EPAIII , EMC | EPAIII , EMC | EPAIII , EMC |
Engine Type | Air-Cooled, 4 Stroke, OHV, Single Cylind | Air-Cooled, 4 Stroke, OHV, Single Cylind | Air-Cooled, 4 Stroke, OHV, Single Cylind |
Starting System | Recoil | Recoil | Recoil/Electric |
Displacement (cc) | 212cc | 301cc | 420cc |
Bore*Stroke(mm) | 70*55 | 80*60 | 90*66 |
Compression Ratio | 8.5:1 | 8.2:1 | 8.0:1 |
Rated Frequency | 50Hz 60Hz | 50Hz 60Hz | 50Hz 60Hz |
Rated Voltage | 220V 120V | 220V 120V&240V | 220V 120V&240V |
Rated Power(kW) | 3.5kW 3.5kW | 5.5kW 5.5kW | 7.8kW 7.8kW |
Surge Power(kW) | 4.0kW 4.0kW | 6.25kW 6.25kW | 8.75kW 8.75kW |
DC Output | 12V / 8.3A | 12V / 8.3A | 12V, 8.3A |
THD(%) | ≤3 | ≤3 | ≤3 |
Fuel Tank Capacity | 7L | 15L | 15L |
Full Load Continuous Running Time | 4h | 9h | 6.5h |
1/2 Load Continuous Running Time | 7h | 12h | 10h |
Noise (7m) | 76dB | 84dB | 84dB |
Dimensions(L*W*H) | 502*350*495mm | 605*514*537mm | 605*514*537mm |
Net Weight (Kg) | 30 | 60 | 65 |
Multi-functional Meter | / | ● | ● |
L5-20R 120V 20A Duplex / | 1＊（Child P rotection） | 2＊GFCI | 2*GFCI |
L5-30R 120V 30A TWISTLOCK | 1 | / | / |
L14-30R 120/240V 30A TWISTLOCK | / | 1 | 1 |
Breaker | 2 | 3 | 3 |
USB Device | 1*1A,1*2.1A | 1*1A,1*2.1A | 1*1A,1*2.1A |
Receptacle Cover | ● | ● | ● |
Parallel Kit | ● | / | / |
Spark Arrestor | ● | ● | ● |
Oil Drain Tube | ● | ● | ● |
Lithium Battery | / | / | ●（1.6Ah） |
Wheels & Kits | / | ●（8”） | ●（8”） |
Took Kit | Spark Plug Socket | Spark Plug Socket & Wheel Wrench | Spark Plug Socket & Wheel Wrench |
Packaging | Color Carton | Color Carton | Color Carton |
40HC loading Quantity (with pallet) 40HC | 528 units | 288 units | 288 units |
40HC loading Quantity (without pallet) | 654 units | 300 units | 300 units |
